Machine Name:Universal Turning Center
Manufacturer:DMG MORI
Model:Ecoturn 450
Year of Manufacture:2016
Machine Id:62
Disclaimer:

This offering is courtesy of the seller. It is offered as a convenience by KRUDO Industrial to its clients and is not intended to convey ownership of these particular machines.

The presented specifications have been prepared by the best of our knowledge and therefore, we cannot be held liable for any errors or omissions! Buyers are invited to inspect the offered Machinery & Equipment at current location prior to purchase.

Universal Turning Center - DMG MORI
Universal Turning Center - DMG MORI
Universal Turning Center - DMG MORI
Universal Turning Center - DMG MORI
Universal Turning Center - DMG MORI

Description:

Working area
Max. swing: 650 mm
Swing over cross slides: 465 mm
Max. turning diameter: 400 mm
Cross travel (X): 267.5 mm
Longitudinal travel (Z): 600 mm
Rapid traverse (X/Z) : 30/30 m/min
Main Spindle
Spindle head (flat flange): 170 h5 mm
Bar capacity: Ø 65 mm / Ø 75 mm
Spindle diameter in the front bearing: 130 mm
Chuck: 250/315
Drive power (40/100% ED): 17.5 kW/12.5 kW
Maximum torque (40/100% ED): 370 Nm/280 Nm
Maximum speed: 4000 rpm
Tool holder
To ISO 230-2 in X/Z axes (indirect measurment system) : 8/8 µm
To ISO 230-2 for C axis: 20 µm
Tool holder
Number of toll stations: 12
of which driven tool stations: 12
Shank diameter: 40 mm
Drive power (40% ED) at 2000rpm: 4.2 kW
Maximum torque (40% ED): 20 Nm
Maximum speed: 4000 rpm

Controls
SIMline withOperate on SIEMENS 840D solutionline

Weight: 5800 kg



#10068
