Machine Name:	(10.09) Assembly of Support Bearing Shield
Manufacturer:	Thyssenkrupp System Engineering
Model:	EC011070
Year of Manufacture:	2018
Location:	Germany
Machine Id:	661
Disclaimer:
The presented specifications have been prepared to the best of our knowledge, and therefore, we cannot be held liable for any errors or omissions! Buyers are invited to inspect the offered Machinery and Equipment at the current location prior to purchase.

(10.09) Assembly of Support Bearing Shield

(10.09) Assembly of Support Bearing Shield

(10.09) Assembly of Support Bearing Shield

(10.09) Assembly of Support Bearing Shield

(10.09) Assembly of Support Bearing Shield

Description:

Parts/Tooling included:

Kistler - Press NCFH 15200300BHCG (max. 15kN)
Kistler - Press control unit
Kistler - Monitor
Atlas Copco - Screwdriver ETV STR61-30-10 (6-35Nm)
Atlas Copco - Screwdriver station PF4000-C-PN-HW
Atlas Copco - Carbo arm
CAB - label dispenser H60
