Main Category > (07.01) Winding - Inserting Machine

Machine Name:(07.01) Winding - Inserting Machine
Manufacturer:Schaeffler ELMOTEC STATOMAT
Model:TFWE1/280-A
Year of Manufacture:2014
Location:Germany
Machine Id:627
Disclaimer:

The presented specifications have been prepared to the best of our knowledge, and therefore, we cannot be held liable for any errors or omissions!

Buyers are invited to inspect the offered Machinery and Equipment at the current location prior to purchase.
(07.01) Winding - Inserting Machine
(07.01) Winding - Inserting Machine
2
(07.01) Winding - Inserting Machine
(07.01) Winding - Inserting Machine

Description:

Technical Specifications:

  • Serial no.: 11 36 12 01 12
  • Total Weight: 9000 kg
  • Admiss. Operating Speed: 140 min1
  • Admiss. Operating Pressure: 6.0 bar
  • Voltage: 400 V
  • Electricity Supply: 11 kVA
  • Frequency: 50 Hz
  • Noise Level: UVV dbA

Parts/Tooling included:

  • 1x Linear Axes

Click here to view 360 Tour

Request an Inspection
Get a Quote
