Main Category > (01.07) Tube Cutting

Machine Name:	(01.07) Tube Cutting
Manufacturer:	Schaeffler ELMOTEC STATOMAT
Model:	ST40
Year of Manufacture:	2019
Location:	Germany
Machine Id:	571
Disclaimer:
The presented specifications have been prepared to the best of our knowledge, and therefore, we cannot be held liable for any errors or omissions! Buyers are invited to inspect the offered Machinery and Equipment at the current location prior to purchase.

(01.07) Tube Cutting

(01.07) Tube Cutting

(01.07) Tube Cutting

(01.07) Tube Cutting

(01.07) Tube Cutting

Description:

Technical Specifications:

Machine No.: 2800/0618/300006845
Electric Power Supply: 3L/N/PE - 400VAC - 50Hz
Power Supply Prefuse: 16A
Rated Short Current: <10kA

Parts/Tooling included:

15 SAB, Tubecutter

Click here to view 360 Tour

Request an Inspection
