Machine Name:(01.10) Lacing Winding Head
Manufacturer:Schaeffler ELMOTEC STATOMAT
Model:BK 2/250-A-ET1
Year of Manufacture:2019
Location:Germany
Machine Id:574
Disclaimer:

The presented specifications have been prepared to the best of our knowledge, and therefore, we cannot be held liable for any errors or omissions!

Buyers are invited to inspect the offered Machinery and Equipment at the current location prior to purchase.
(01.10) Lacing Winding Head
2
(01.10) Lacing Winding Head
(01.10) Lacing Winding Head
(01.10) Lacing Winding Head

Description:

Technical Specifications:

  • Serial No.: 11 18 02 16
  • Total Weight: 3200 kg
  • Admiss. Operating Pressure: 6.0 bar
  • Voltage: 400 V
  • Electricity Supply: 10.0 kVA
  • Frequency: 50 Hz
  • Noise Level: UVV dbA

Click here to view 360 Tour

Request an Inspection
Get a Quote
