Description:

Cylindrical Grinding Machines - TSCHUDIN HTG 400

Main data:

• Distance between tips: 400 mm
• Tip height: 100 mm

Table:

• Longitudinal travel max.: 400 mm

Grinding headstock:

• Grinding wheels: Ø 350 mm
• Grinding wheel width for Ø 350 to 50 mm
• Continuous feed up to 0.8 mm/Ø

Work headstock:

• MK 4 taper mount
• Orientation: 360
• Continuous speed regulation: 65 - 500 rpm

Tailstock:

• Inner taper of quill: MK 3
• Adjustment travel of the quill: 20 mm
• Quill height: 100mm
• Quill spring force: 4-15 kp

Dimensions:

• Length: 2220 mm
• Width: 1200 mm
• Height: 1350 mm
• Net weight: 1600 kg
