Description:

Largest workpiece diameter: 150 mm
Max. workpiece diameter: 280 mm
Largest swing diameter above the table:200 mm
Height of the workpiece spindle above the floor: 1250 mm
Workpiece spindle speeds NC-programmable
Table strokes:
Z1 axis : 600 mm
Z2 axis : 400 mm
Z3 axis : 400 mm
X1 axis : 280 mm
X2 axis : 280 mm
X3 axis : 280 mm
Table speed infinitely adjustable:
Z axes : 0 - 30 m / min
X axes : 0 - 30 m / min
Infeed speed infinitely variable: 0.01 - 15 mm / min
Infeed depending on the stroke: 0.0005 - 0.1 mm
Workpiece spindle positioning: C-axis
Connected load of the machine: approx. 50 kW
Control: Siemens SINUMERIK 840D
Weight: 9000 kg

#10124
